| Model | E-3200PRO | |
| Voltage | 12V/24VDC | |
| Rated Current | 55A/30A | |
| Cooling capacity | 3200W | |
| Heating capacity | 2000W | |
| Power | 760W - 1065W | |
| Compressor | Model | Electric scroll compressor |
| Displacement | 18cc/r | |
| Rotate Speed | 1500 - 4500rpm | |
| Evaporator blower air vol. | 700m3/h | |
| Condenser fan air vol. | 1100m3/h | |
| Refrigerant/Volume | R134a/330g | |
| Dimensions | 885*710*290mm | |
| Weight | 35kg | |
| Vehicle Applications | All trucks, construction machinery , tractor etc. | |
