| MODEL | SC356AD-120V | SC356AD-220V | SC356AD-48V | SC356AD-72V |
| Room Temperature range | -20℃ to 15℃ | -20℃ to 15℃ | -20℃ to 15℃ | -20℃ to 15℃ |
| Max. operating temperature | 40℃ | 40℃ | 40℃ | 40℃ |
| Room Volume | 12~18m³ | 12~18m³ | 12~18m³ | 12~18m³ |
| Voltage consumption | Single Phase 115V,60Hz | Single Phase 220V,50/60Hz | 48V DC | 72V DC |
| Cooling capacity(W/BTU) | 3180W | 3180W | 2800W | 2800W |
| Power consumption | 1800W | 2200W | 2064W | 2780W |
| Current consumption LRA | 56A | 50A | 140A | 117A |
| Current consumption FLA | 15A | 9.9A | 48A | 39A |
| Defrosting | Hot gas defrost | Hot gas defrost | Hot gas defrost | Hot gas defrost |
| Defrosting consumption | 1200W | 1800W | 1464W | 2180W |
| Air flow Evaporator | 1200m³/h | 1200m³/h | 1200m³/h | 1200m³/h |
| Air flow Condenser | 1300m³/h | 1300m³/h | 1300m³/h | 1300m³/h |
| Protection class | IP54 | IP54 | IP54 | IP54 |
| Refrigerant | R404A CFC Free | R404A CFC Free | R404A CFC Free | R404A CFC Free |
| Refrigerant Charge | 1.1Kg | 1.2Kg | 1.2Kg | 1.2Kg |
| Weight | 80kg | 80kg | 80kg | 80kg |
| Compressor model | GY27 | GY27 | GY27 | GY34 |
| Compressor displacement | 27ml/rev | 27ml/rev | 27ml/rev | 34ml/rev |
| Opening size | 1070mm*356mm | 1070mm*356mm | 1070mm*356mm | 1070mm*356mm |
