| Model | SF-700Pro | |
Cooling Capacity |
Temperature | Watts |
| 0℃ | 6870W | |
| -20℃ | 3650W | |
| Type | Split unit vehicle engine driven type | |
| Refrigerant & Qty | R404A,3.0kg±5% | |
| Box Inside Temp | -25℃ ~ +30℃ | |
| Defrosting type | Hot gas defrost(Auto/Manual) | |
| Condenser | Type | Parallel Flow Condenser |
| Fan Quantity | 2Pcs | |
| Fan Type | Axial type | |
| Air Flow Volume | 1800 m³/h | |
| Dimensions | 1410*543*503mm | |
| Weight | 53Kg | |
| Evaporator | Type | Inner Grooved Copper Tube and Fin |
| Fan Quantity | 3Pcs | |
| Fan Type | Axial type | |
| Air Flow Volume | 2310 m³/h | |
| Dimensions | 1230*550*300 mm | |
| Weight | 37Kg | |
| Compressor | Model | QP21 |
| Type | Swash plate type | |
| Displacement | 213cc/r | |
| Refrigerated Oil | RL-68H | |
| Applicable Box Volume | 35~45m³ | |
| Optional function | Heating and Electric standby | |
